Frame
Carbon HMF, Integrated Suspension Technology, Virtual 4 Link kinematic, Adjustable head angle, Syncros Cable Integration System, TQ HPR60, UDH Interface, 12x148mm with 55mm Chainline
-
Travel
Front: 160mm, Rear: 155mm
-
Fork
FOX 36 Rhythm Air Grip, Sweep Adj., 15x110mm QR axle, tapered steerer, 44mm offset, Reb. Adj., Lockout, 160mm travel
-
Rear Shock
FOX FLOAT X NUDE EVOL Piggy Back Trunnion, SCOTT custom w. travel, geo adj., 3 modes: Climb-Ramp Control-Descend, Custom large Air volume, Comp & Reb. Adj. Travel 155-100-Climb, T185X55mm
-
Remote System
TracLoc Technology, Rear Suspension & Dropper Remote, 3 Rear Suspension modes
-
Drive Unit
TQ HPR60 Mid Motor drive 60Nm max Torque, EU: 25kmh, US: 20mph
-
Battery
TQ Internal 360Wh + TQ Range Extender 160Wh
-
Display
TQ HPR, Bluetooth, ANT+, Dedicated Smartphone app
-
Charger
TQ 100-240V-4A
-
Rear Derailleur
SRAM S1000 Eagle AXS Transmission 12 Speed, Wireless Electronic Shift System
-
Shifters
SRAM AXS Rocker Pod Controller
-
Crankset
Praxis Alloy
-
Chainguide
e*thirteen, e*spec Slider
-
Chainring
Praxis alloy spider, SRAM Eagle Transmission 34T chainring
-
Chain
SRAM CN GX Eagle Transmission
-
Cassette
SRAM Eagle XS 1270 Transmission 10-52
-
Brakes
SRAM Maven Bronze Stealth 4-Piston Disc
-
Rotor
SRAM HS2 Rotors F&R 200mm
-
Handlebar
back sweep 8°, 780mm, Syncros Hixon 1.5 Alloy 7050, Size S & M 15mm rise, Size L & XL 25mm rise, Syncros Endurance lock-on grips
-
H'stem
Syncros AM 1.5, 4° rise, 7050 Alloy, 31.8mm, 1 1/8", Syncros Cable Integration System
-
Seatpost
Syncros Duncan Dropper Post 1.5s, Travel Adjust, 31.6mm, S size 140mm, M size 180mm, L size 180mm, XL size 210mm
-
Seat
Syncros Tofino 1.5 Regular, Titanium rails
-
Headset
Syncros - Acros Angle adjust & Cable Routing HS System, Stainless, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB
-
Hub (Front)
Formula CL-811, 15x110mm
-
Hub (Rear)
Formula CL-148S, 12x148mm
-
Spokes
Stainless Black 15G, 1.8mm
-
Rims
Syncros X-30S, 32H, 30mm, Sleeve Joint, Tubeless ready
-
Front Tire
Maxxis Assegai, 2.5", 60TPI Foldable, Tubeless Ready, EXO+ 3C Maxx Terra
-
Rear Tire
Maxxis Dissector, 2.5", 60TPI Foldable, Tubeless Ready, EXO+ 3C Maxx Terra
-
Extras
SRAM AXS Extension Cord
-
Approx weight in KG
19.9 Tubless setup without RE (1.1kg)
-
Approx weight in LBS
43.87 Tubless setup without RE (1.1kg)
-
Max. System Weight
130kg, The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
