Frame
Scale Alloy 6061 Custom Butted Tubing, Syncros Cable Integration System BB92, UDH Interface, 12x148mm with 55mm Chainline
-
Fork
RockShox Judy Silver TK Solo Air 15x110mm QR axle, 51mm offset, Tapered Steerer Reb. Adj., Lockout, 110mm travel
-
Remote System
RockShox PopLoc Remote
-
Rear Derailleur
SRAM NX Eagle 12 Speed
-
Shifters
SRAM SX Eagle Trigger
-
Crankset
SRAM SX Eagle DUB 55mm CL, 32T
-
BB-Set
SRAM DUB PF 92 MTB Wide, shell 41x92mm
-
Chain
SRAM CN SX Eagle
-
Cassette
SRAM SX-PG1210, 11-50 T
-
Brakes
Shimano MT200 Disc Brake
-
Rotor
Shimano SM-RT10 CL, 180/F and 160/R
-
Handlebar
Syncros Alloy 6061 T shape Flat, 9°, 740mm Syncros Performance XC lock-on grips
-
H'stem
Syncros Alloy 6061 oversized 31.8mm, 1 1/8", 6° angle
-
Seatpost
Syncros Duncan Dropper, 31.6mm XS&S size 100mm, M size 130mm, L &XL size 150mm
-
Seat
Syncros Belcarra Regular 2.5
-
Headset
Syncros - Acros OE Cable Routing HS System OD 50/62mm, ID 42/56mm
-
Hub (Front)
Formula CL-811, 15x110mm
-
Hub (Rear)
Formula CL-3248, 12x148mm
-
Spokes
Stainless Black 15G, 1.8mm
-
Rims
Alex X-25/ 32H, 25mm Tubeless ready
-
Front Tire
Maxxis Rekon Race, 29x2.4", EXO, Tubeless Ready
-
Rear Tire
Maxxis Rekon Race, 29x2.4", EXO, Tubeless Ready
-
Approx weight in KG
13.7 (Tubless setup without pedals)
-
Approx weight in LBS
30.20 (Tubless setup without pedals)
-
Max. System Weight
130kg The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
